Circular Saw Blades · Solid Carbide · for Rohbi and Pressta-Eisele Machines
Outside dia. 100 - 200
Cat.-No. 5130
Cat.-No. 5130
Optional modification: coatings and/or alternating chamfers.
For high performance sawing machines.
For special use on Rohbi, Bimax-, Pressta-Eisele and other machines in abrasive and high-tensile materials.
Toothing optimized for application. For toothing one additional week delivery time.
Tools with bore ø 32 mm have two driving pin holes ø 8,5 mm on pitch circle 45 mm. The saws are polished and have an axial runout tolerance ≤ 0,05 mm.
Request article by clicking on the corresponding line.
| d1 mm |
l1 mm |
d2 mm |
Teeth | Hub-Ø mm |
ae max mm |
Cat.-No. | Item-No. | |
| 100 | 0,5 | 22 | nach Kundenwunsch | 44 | 26,5 | 5130 | 51301000500001 | |
| 125 | 0,8 | 22 | nach Kundenwunsch | 44 | 39 | 5130 | 51301250800001 | |
| 160 | 1 | 22 | nach Kundenwunsch | 44 | 56,5 | 5130 | 51301601000001 | |
| 160 | 1,2 | 22 | nach Kundenwunsch | 44 | 56,5 | 5130 | 51301601200001 | |
| 180 | 1,2 | 22 | nach Kundenwunsch | 44 | 66,5 | 5130 | 51301801200001 | |
| 200 | 1,2 | 22 | nach Kundenwunsch | 44 | 76,5 | 5130 | 51302001200001 | |
